0.38/0.66KV-0.66/1.14KV Mining Movable Rubber Sheathed Screened Or Unscreened Flexible Cable
APPLICATION
Movable Rubber Sheathed Flexible Cable is mainly applied for movable electrical equipments and coal cutter.
CABLE STANDARDS
Movable Rubber Sheathed Flexible Cable is manufactured according to the standards MT818.
TYPE AND NAME OF CABLE
| Type | Rated Voltage (KV) | Name | Application |
|---|---|---|---|
| MY | 0.38/0.66 | Moveable rubber sheathed flexible cable for coal mine | For power-supply connections of various moveable coal mine equipment in well of rated voltage 0.38/0.66KV |
| MYE | 0.38/0.66 | Moveable elastomer sheathed flexible cable | For power-supply connections of various moveable coal mine equipment in well of rated voltage 0.38/0.66KV |
| MYP | 0.38/0.66 | Moveable rubber sheathed flexible cable with screen | For power-supply connections of various moveable coal mine equipment in well of rated voltage 0.38/0.66KV |
| MYPE | 0.38/0.66 | Moveable elastomer sheathed flexible cable with screen | For power-supply connections of various moveable coal mine equipment in well of rated voltage 0.38/0.66KV |
| MYP | 0.66/1.14 | Moveable rubber sheathed flexible cable with screen | For power-supply connections of various moveable coal mine equipment in well of rated voltage 0.66/1.14KV |
| MYPE | 0.66/1.14 | Moveable elastomer sheathed flexible cable with screen | For power-supply connections of various moveable coal mine equipment in well of rated voltage 0.66/1.14KV |
| Type | Rated Voltage (KV) | Nominal Cross-sectional Area of Main Core(mm²) | Number of Cores(Main Core) | Number of Cores(Earthing Core) | Number of Cores(Monitoring Core) |
|---|---|---|---|---|---|
| MY | 0.38/0.66 | 50-400 | 1 | 0 | 0 |
| MYE | 0.38/0.66 | 50-400 | 1 | 0 | 0 |
| MY | 0.38/0.66 | 4-185 | 3 | 1 | 1 |
| MYE | 0.38/0.66 | 4-185 | 3 | 1 | 1 |
| MYP | 0.38/0.66 | 4-185 | 3 | 1 | 1 |
| MYPE | 0.38/0.66 | 4-185 | 3 | 1 | 1 |
| MYP | 0.66/1.14 | 10-185 | 3 | 3 | 3 |
| MYPE | 0.66/1.14 | 10-185 | 3 | 3 | 3 |
