0.66/1.14KV Coal Cutter Semi-conducting Screened Monitoring Braided Or Lapping Reinforced Flexible Cable
APPLICATION
Coal Cutter Flexible Cable With Shield is mainly applied for movable electrical equipments and coal cutter.
CABLE STANDARDS
Coal Cutter Flexible Cable With Shield is manufactured according to the standards MT818.
TYPE AND NAME OF CABLE
| Type | Rated Voltage (KV) | Name | Application |
|---|---|---|---|
| MCPJB | 0.66/1.14KV | Coal cutter semi-conducting screened monitoring braided reinforced flexible cable | For power supply of coal cutter or similar equipment of rated voltage 0.66/1.14KV.The cable can be directly used by trailing. |
| MCPJR | 0.66/1.14KV | Coal cutter semi-conducting screened monitoring laping reinforced flexible cable | For power supply of coal cutter or similar equipment of rated voltage 0.66/1.14KV.But the cable should be laid in shield scraping belt. |
| Type | Rated Voltage (KV) | Nominal Cross-sectional Area of Main Core(mm²) | Number of Cores(Main Core) | Number of Cores(Earthing Core) | Number of Cores(Monitoring Core) |
|---|---|---|---|---|---|
| MCPJB | 0.66/1.44 | 35-95 | 3 | 1 | 2 |
| MCPJR | 0.66/1.44 | 35-95 | 3 | 1 | 2 |
