Plastic Insulated Control Cable KYJYP2-23

APPLICATION
Copper Conductor XLPE Insulated Copper Tape Screened Steel Armoured PE Sheathed Control Cable (KYJYP2-23) is mainly used for system connection wire of control,signal,protection or measuring for rated voltage up to and including 450/750V.

CABLE STANDARDS
GB/T,JB/T,IEC,BS,DIN,ICEA up on request.

BASIC INFORMATION
Code Name
KYJYP2-23
Rated Voltage (Uo/U)
450/750V
Cable Structure
CU/XLPE Insulation/PE Inner Sheath/Copper Tape Screened/Steel Tape Armoured/PE Outer Sheath

CONSTRUCTION
Conductor
Preferred Number of cores:
4,5,7,8,10,12,14,16,19,24,27,30,37,44,48,52,61
The conductors shall comply with the requirement given in IEC 60228 for class 1 or 2.
– class 1 for solid conductors;
– class 2 for stranded conductors.
Insulation
Cross-linked Polyethylene XLPE according to IEC
Metallic Screened
Copper Tape
Metallic Armoured
Steel Tape
Sheathed
PE(Polyethtlene) according to IEC
Other special application cable can be provided upon requests:
Fire-resistant,Flame-retardant,Low-halogen,Non-halogen,Low-fume,Low-smoke,as well as acid-alkali-proof,High temperature resistant,Termite and Rodent resistant, Water proof series and so on.

CHARACTERISTICS
Conductor temperature
Maximum conductor temperature in normal use: 90℃
Installation temperature
Ambient temperature under installation shall not be below 0℃
Max.temperature of conductor under short circuit-(Max.Duration 5 sec.)
XLPE Insulated:250℃
Preferred Permissible bending radius
For Armoured XLPE insulated cable not less than: 12 times of cable diameter
